MIL-W-83420D | ||||||||
NOMINAL |
| (A） | （B） |
| ||||
INCH | MM | 7*7 | LB | KN | LB | KN | LBS/100FT | KG/100M |
3/64 | 1.19 | 7*7 | 270 | 1.20 | 270 | 1.20 | 0.42 | 0.62 |
1/16 | 1.59 | 7*7 | 480 | 2.14 | 480 | 2.14 | 0.75 | 1.12 |
3/32 | 2.38 | 7*19 | 920 | 4.09 | 920 | 4.09 | 1.60 | 2.38 |
3/32 | 2.38 | 7*19 | 1000 | 4.45 | 920 | 4.09 | 1.74 | 2.59 |
1/8 | 3.18 | 7*19 | 2000 | 8.90 | 1760 | 7.83 | 2.90 | 4.31 |
5/32 | 3.97 | 7*19 | 2800 | 12.46 | 2400 | 10.68 | 4.50 | 6.70 |
3/16 | 4.76 | 7*19 | 4200 | 18.69 | 3700 | 16.46 | 6.50 | 9.67 |
7/32 | 5.56 | 7*19 | 5600 | 24.92 | 5000 | 22.25 | 8.60 | 12.80 |
1/4 | 6.35 | 7*19 | 7000 | 31.15 | 6400 | 28.48 | 11.00 | 16.37 |
9/32 | 7.14 | 7*19 | 8000 | 35.60 | 7800 | 34.71 | 13.90 | 20.68 |
5/16 | 7.94 | 7*19 | 9800 | 43.61 | 9000 | 40.05 | 17.30 | 25.74 |
3/8 | 9.53 | 7*19 | 14400 | 64.08 | 12000 | 53.40 | 24.30 | 36.16 |
